    4 inch Touch LCD Shield for Arduino

    £22.99
    Stückpreis  pro
    Features
    1. Resistive touch screen TFT LCD, 4inch, 480x320 resolution
    2. Standard Arduino interface, compatible with development boards like : Arduino UNO, Leonardo, UNO PLUS, NUCLEO, XNUCLEO
    3. Onboard stand-alone touch controller, better touching than solutions that use AD pins directly for touch control
    4. PWM backlight control, allows to adjust the backlight to a comfortable level
    5. Micro SD slot, provides an easy way to store photos for displaying
    6. Controlled via SPI, only a few Arduino pins are used
    7. Comes with STM32 and Arduino examples, convenient for porting

    Key Parameters
    1. LCD Type: TFT
    2. LCD Interface: SPI
    3. LCD Controller: ILI9486
    4. Touch Screen Type: Resistive
    5. Touch Screen Controller: XPT2046
    6. Colors: RGB, 65K colors
    7. Resolution: 480x320 (Pixel)
    8. Aspect Ratio: 8:5
    9. I/O Voltage: 3.3V/5V

    Wiki : www.waveshare.com/wiki/4inch_TFT_Touch_Shield


    Specification:
    Package Weight
    One Package Weight 0.11kgs / 0.24lb
    One Package Size 10cm * 7cm * 2cm / 3.94inch * 2.76inch * 0.79inch
    Qty per Carton 600
    Carton Weight 15.00kgs / 33.07lb
    Carton Size 60cm * 35cm * 40cm / 23.62inch * 13.78inch * 15.75inch
    Loading Container 20GP: 317 cartons * 600 pcs = 190200 pcs
    40HQ: 736 cartons * 600 pcs = 441600 pcs
