LTN156AT37 15.6 inch 30 Pin 16:9 High Resolution 1366 x 768 Laptop Screens LED TFT Panels

Mobile Parts

LTN156AT37 15.6 inch 30 Pin 16:9 High Resolution 1366 x 768 Laptop Screens LED TFT Panels

Name: LTN156AT37 15.6 inch 30 Pin 16:9 High Resolution 1366 x 768 Laptop Screens LED TFT Panels
Brand: Mira Sales
SKU: CLS2309
Price: 32.99 GBP
Availability: InStock

£32.99

1. High quality replacement screen panel.
2. High resolution 1366 x 768 pixel.
3. 16:9 aspect ratio standard screen.
4. 15.6 inch diagonal screen size.
5. Backlight Lamp: LED type.

Specification:

General

Model

LTN156AT37

Screen Size

15.6 inch

Screen Type

LCD module, a-Si TFT-LCD

Resolution

1366 (RGB) x 768 (WXGA)

Brightness (cd/m2)

200

Power Supply

3.3V

Connector

eDP (1 Lane), 30 pin, Terminal

Working Mode

TN, Normal white display, Transmissive

Display Color

262k 45%(CIE1931)

Contrast Ratio

500:1

Viewing Angle

45/45/20/40(CR>=10)

Shape Style

Medium thick screen (PCBA Straight, 3.4~4mm)

Surface

Mirror (Haze 0%)

Backlight Type

9S4P WLED, 15K hours, with LED diver

Response Speed

12 (Typ.) (Tr + Td) ms

Display Size

344.232 x 193.536

Size	3621.70.3cm

Weight

379g

Environment

Operating Temperature

-20 ~ 60 Degrees Celsius

Storage Temperature

0~50 Degrees Celsius

Package Weight

One Package Weight

1.15kgs / 2.54lb

One Package Size

45cm * 33cm * 8cm / 17.72inch * 12.99inch * 3.15inch

Qty per Carton

Carton Weight

12.50kgs / 27.56lb

Carton Size

62cm * 40cm * 30cm / 24.41inch * 15.75inch * 11.81inch

Loading Container

20GP: 358 cartons * 10 pcs = 3580 pcs
40HQ: 832 cartons * 10 pcs = 8320 pcs
