Specification:
Clamp Body Length: 130mm
Clamp Body Width: 130mm
Clamp Height: 37mm
Installation Hole Distance: 94mm
Maximum Opening: 65mm
Jaw Width: 65mm
Jaw Height: 20mm
Screw Diameter: 13.5mm
Net Weight: 1.3kg
How to Install:
1. Take out all the items in the package (one vise + four sets of bolts)
2. Place the vise on the console horizontally, and the screw rod is perpendicular to the edge of the console
3. Use the drilling tool to punch holes in the four corners of the bench vise
4. Rotate the bolts into the four cavities
5. Tighten the bolts to fix the bench vise and use it
Instructions:
1. Rotate the screw handle to separate the jaws
2. Place the item to be sanded in the center of the jaws
3. Rotate the screw handle to make the jaws fix the itemUser Target Audience:
Holding wood: sawing wood without loosening or slipping
Holding metal: Grinding metal has a strong bite
Holding glass: cutting glass securely
